What is The Difference Between Hydroponics and Aquaponics?

By Charlie Pearson

A Guide to Understanding the Difference Between Hydroponics and Aquaponics

You may be wondering what the difference between hydroponics and aquaponics is. Great question!

Aquaponics is simply a hydroponic system with fish. Instead of adding store bought (or homemade) nutrients to your hydro system, you raise fish in a tank and then feed that water to your plants. You monitor the temperature of the water in the fish tank and feed the fish a high quality diet. They eat the food you give them, and in turn their waste turns into the food for the plants. It is generally a closed system where the fish water is pumped directly to the plants.

That's it! That's aquaponics. But if that's the way you're going, you are also a fish caretaker. You have to really monitor the temperature of the fish water. An entire tank of fish can die off if they get too hot in a greenhouse aquaponic system. Fish can also be susceptible to diseases which will sicken or kill them.

Before starting a hydroponic fish tank, think about whether you can provide a nice life for the fish as well as for your plants. Stressed fish will not provide good nutrition for your plants.

Fish need space: Plan on plenty of room for your fish

Fish need food: Feed your fish a high quality diet so they can produce high quality nutrition for your plants

Fish need light: Please don't keep fish in a sad, dark tank. If you have a small home aquaponic system with goldfish or koi, you can even dress up their tank with some plants.

Monitor your water temperature: Here is where a water heater or chiller is so important. Although some fish can withstand a variety of temperatures, they still have to stay in a certain range.

Do your research: Be sure the fish you are buying are the right fish for your space and climate. If you are planning to eat them, know how long it takes to grow them from fry to adult. Learn about fish diseases, and how to prevent and treat them.

There are some aquaponic kits you can buy that fit right on top of an aquarium. Some countertop models have the fish tank built in with a nice window for fish viewing.

If you don't have enough fish in your tank, you won't have enough nutrients for your plants, so plan accordingly.

What Do You Call Hydroponics With a Fish Tank? Aquaponics!

Aquaponics is a combination of aquaculture, which is growing fish and other aquatic animals, and hydroponics, which is growing plants in water. In aquaponics, everything starts with fish food, which works as the system's input. As fish eat this food and process it, they transform it into urine and faecal matter, both rich in ammonia, which can be toxic to plants and fish in sufficient quantities. Next, the water (now rich in ammonia) flows from the fish tank into a biofilter together with uneaten food and decaying plant matter. Afterwards, the bacteria in the biofilter break everything down into organic nutrient solutions (nitrogen-rich) for growing vegetables.

So, in hydroponics with a fish tank (properly called aquaponics) everything relies on 3 main components: the fish, the nitrifying bacteria, and the plants, and all of them depend on each other to survive. Without the bacteria to consume the fish waste, plants wouldn't have a usable form of nutrients, which is why biological filtration is crucial. And thanks to plant growth, nutrients are removed from the water, leaving it clean for the fish.

Since aquaponics uses basically the same systems as hydroponics, there aren't many differences in how the system works, except for the added fish in the water tank. Ebb and flow, drip, deep water culture (DWC), and nutrient film technique (NFT) can be used with aquaponics. There are also media-based aquaponic systems, and these are the most common and popular type of aquaponic system. In this system, there is a fish tank and a grow bed with the growing medium, such as gravel or expanded clay pellets, that provide a surface for beneficial bacteria to break down fish waste and turn it into nutrients. The water is pumped from the fish tank to the grow bed and is then returned to the fish tank.

Be careful however when using a closed-loop system where the water is reused like Kratky, DWC. By doing so, you're removing the water from its biofilter, which comes with the risk of a pathogen bloom (poison).

If you want to use the water in a hydroponic setup (closed loop), you should include a medium that supports microbes, such as clay pebbles (ebb & flow) or biochar (drip).

You can have any freshwater fish in an aquaponic system, most popular being tilapia and barramundi because they tolerate better diverse water conditions and they grow fast. Trout can also be used especially for lower water temperatures. Other aquatic animals you can grow are snails and shrimp.

In a small aquaponic system you can grow vegetables that are not heavy feeders, like lettuce, kale, spring onions and leeks, radishes, spinach, okras, rocket (arugula), mint, herbs, watercress, decorative flowers, and other small vegetables. Heavy feeders, like tomatoes, cucumbers, beans, broccoli, cabbage, cauliflower, and strawberries, require more nutrition and a more advanced aquaponic system. You should also avoid growing plants that need acidic or alkaline water because those pH levels can definitely harm the fish.

Building an Aquaponic System

Supply List

• Fish tank (preferably 20-40 gallons (75-150L))
• Growing tray/container
• Air pump with tubing and air stone
• Submersible water pump
• PVC pipes or similar tubing
• Bulkheads or universal seals
• Growing medium (clay pebbles work best)
• Fish
• pH and EC meter
• Grow lights

Step 1: Set Up a Fish Tank

First, you need to choose a fish tank. You can use a standard 10, 20, or 40-gallon fish tank, or opt for something more affordable. Many DIY aquaponic systems are made with food-grade containers, like totes or large rain barrels.

You'll need to set the tank up as you would a normal fish tank. Dechlorinate the water and allow it to cycle for 4-6 weeks before you add any fish. This gives the bacteria time to build up so that there is enough present to break down the ammonia and nitrites into the nitrates needed to feed your plants. Make sure to include a submersible water pump inside the tank and an air pump outside the tank.

Step 2: Make a Media Bed

DIY media beds (also known as grow beds) are typically made out of shallow totes, plastic trays or bus bins, or even wood lined with heavy-duty plastic sheets. Make sure that your grow bed has the same (or very close) volume as your fish tank.

When you've decided what you will use for the grow bed, you need to create a support system for it. You can use a table or shelving to support it. Keep in mind that the bed will be quite heavy when the growing medium and plants are added, not to mention water.

It's best to position the grow bed just above the fish tank, but you can also place it to the side of the tank if supporting its weight is an issue. However, you may need an additional water pump in this case. Once your bed is in position, it's time to add the bulkheads.

Do so by drilling out holes and inserting the bulkheads. Most of the time, they come with gaskets that create a watertight seal. If yours don't have seals, use rubber cement or a universal sealer to make sure there are no leaks. Now, add the growing medium, and that's it, you've set up your grow bed successfully!

Step 3: Set Up the Piping

Now you need to connect your PVC pipe to the bulkhead you installed on the bottom of the media bed and position it down into the fish tank. Also, connect a proper length of tubing to the outlet on the water pump, and run it to the top of the media bed. Once connected, the water pump will send water to the grow bed, and after soaking plant roots, it will drain out through the PVC pipes and return to the fish tank.

Step 4: Add Fish to the System

Once your tank has cycled properly, you can add the fish. There are a variety of different fish that work well in an aquaponics set up. Common choices include tilapia, barramundi, goldfish, koi, pacu, and any ornamental fish, such as guppies, tetras, or mollies.

Make sure to check the water pH level. Fish prefer pH levels between 6.8 and 7.2. Fish waste is acidic, so it will change the pH level of water, and you need to check it regularly to ensure it is within normal levels. If they aren't balanced enough for the type of fish you will use, use liquid pH and EC adjusters to fix the issue.

Step 5: Add Plants to the System

Once everything is set up, it's time to add the plants. Depending on how you set up your grow bed, you can add plants to individual netted pots sunk into the growing media or set the roots of each plant into the bed and cover them with the growing medium so that they are properly anchored.

As mentioned previously, if you have a small system, you should grow plants that are light feeders, such as lettuce, kale, spring onions and leeks, radishes, spinach, and herbs. If you have a heavily stocked tank and well established set up, you can try growing heavy feeders, like tomatoes, cucumbers, peppers, beans, or strawberries.

Once you've added the plants to your aquaponic system, set up your grow lights, and your system is ready to go!

Step 6: Maintain Your Aquaponic System

Maintaining an aquaponic system is not as difficult as it might seem. You'll need to feed your fish a quality diet. You can use a simple flake food and give them the occasional treat. Only feed your fish as much as they can eat in around 5 minutes, 2-3 times per day.

You'll need to test the tank water every week to check the pH, ammonia, nitrite, and nitrate levels. Ammonia and nitrite levels should always be non-detectable, and the nitrites should be low if the plants are doing their job properly. The pH should be neutral, between 6.8 and 7.2, which is ideal for the fish, the plants, and the bacteria. As mentioned previously, water pH level will often drop because fish waste makes water more acidic, so you'll need to raise the pH level by using liquid pH adjusters. In a well-balanced aquaponic system, you will never need to change the water completely, but you will need to top it up because some water will be absorbed by plants.

Make sure to check your tank for dead fish regularly and remove them if you find any. Also, check your plants for pests and diseases often. Keep an eye on the water temperature. It should be between 68 and 86°F (20-30°C). If the water becomes too hot, you can place ice packs into the aquarium or purchase an aquarium chiller. It is not a cheap investment, but if you live in a hot climate, it is definitely worth it. Aquarium chillers can cool down water in your aquarium quickly, and they do it automatically, so you won't have to add ice packs all the time and watch the temperature.

Aquarium chillers operate a coil placed inside your aquarium. When the temperature hits a certain level, the machine kicks in and chills the coil, which then cools the water. If the water becomes too cold, you can purchase an aquarium water heater. They are really easy to use. Simply slip them into your hydroponic water reservoir, turn them on, and let them do their job. Once the ideal temperature is reached, the heater shuts off automatically. When your hydroponic water temperature starts to cool down again, the unit will turn back on and heat it up.
